Origin, History and Characteristics
(Cendree, Mountain blue, Copper blue, Ongaro, Azure Biadetti of Spain, Azure of the Magna)
Latin borrowed a Persian word for blue, "lāzaward," which in the form of lazurium became azurium, and gave us our word azure. Azurite is composed of a basic carbonate of copper, found in many parts of the world in the upper oxidized portions of copper ore deposits. Azurite mineral is usually associated in nature with malachite, the green basic carbonate of copper that is far more abundant. Azurite was the most important blue pigment in European painting throughout the middle ages, and Renaissance by contrast, despite the more exotic and costly ultramarine having received greater acclaim "While a subtle range of blues could be achieved by controlling the particle size of azurite, its green undertone was not always desired; this was adjusted however by mixing in red lakes and, as noted, applying layers of ultramarine on top. The situation changed in the early 1500s with the invention (or more correctly, the re-invention) of smalt. Just when silver mines were becoming more difficult to exploit and less profitable, further economic pressure came as vast quantities of silver were discovered in the New World and imported into Europe, especially through Spain.
The major sources of azurite in Europe were present-day Germany, Hungary, Austria and Central Europe. Canny mine operators and owners therefore began to exploit their mines for rarer metal ores and minerals that could be used by the color industry."B. H. Berrie, "Mining for Color: New Blues, Yellows, and Translucent Paint," Early Science and Medicine 20, nos. 4-6 (2015): 308-334, https://doi.org/10.1163/15733823-02046p02. Azurite—then commonly called azzurro d'Alemagna—was often used for draperies, particularly in works by Duccio and his circle.
>
fig. 1 A Lady with a Squirrel and a Starling (Anne Lovell?)
Hans Holbein the Younger
c. 1526-1528
Oil on oak, 56 x 38.8 cm.
National Gallery, London
The background of Holbein's portrait, which is particularly well preserved, reveals the strong greenish tone of azurite. The background was painted with two separate layers of grainy azurite, the most colorful variation of the pigment, mixed with lead white. The pigments were bound by linseed oil.
fig. 2 Powdered azurite
To prepare a color from azurite, a lump of it is ground into a powder (fig. 2), and sieved. Coarsely ground azurite produces dark blue, and fine grinding produces a lighter tone; however if not ground fine enough, it is too sandy and gritty to be used as a pigment. The medieval system included washing it to remove any mud and then separating the different grains by some process of levigation. If plain water is used it is a slow, laborious process, so they used solutions of soap, gum and lye. When azurite is washed, the very fine particles are rather pale, greenish sky-blue, and not much admired for painting. The best grades of azurite for painting were coarse: not sandy, but so coarse that it could be quite laborious to lay them on.
LOOKING OVER VERMEER'S SHOULDER
The complete book about Johannes Vermeer's and 17th-century fine-painting techniques and materials
by Jonathan Janson | 2020
Enhanced by the author's dual expertise as both a seasoned painter and a renowned authority on Vermeer, Looking Over Vermeer's Shoulder offers an in-depth exploration of the artistic techniques and practices that elevated Vermeer to legendary status in the art world. The book meticulously delves into every aspect of 17th-century painting, from the initial canvas preparation to the details of underdrawing, underpainting, finishing touches, and glazing, as well as nuances in palette, brushwork, pigments, and compositional strategy. All of these facets are articulated in an accessible and lucid manner.
Furthermore, the book examines Vermeer's unique approach to various artistic elements and studio practices. These include his innovative use of the camera obscura, the intricacies of his studio setup, and his representation of his favorite motifs subjects, such as wall maps, floor tiles, and "pictures within pictures."
By observing closely the studio practices of Vermeer and his preeminent contemporaries, the reader will acquire a concrete understanding of 17th-century painting methods and materials and gain a fresh view of Vermeer's 35 masterworks, which reveal a seamless unity of craft and poetry.
While the book is not structured as a step-by-step instructional guide, it serves as an invaluable resource for realist painters seeking to enhance their own craft. The technical insights offered are highly adaptable, offering a wealth of knowledge that can be applied to a broad range of figurative painting styles.
LOOKING OVER VERMEER'S SHOULDER
author: Jonathan Janson
date: 2020 (second edition)
pages: 294
illustrations: 200-plus illustrations and diagrams
formats: PDF
$29.95
CONTENTS
- Vermeer's Training, Technical Background & Ambitions
- An Overview of Vermeer’s Technical & Stylistic Evolution
- Fame, Originality & Subject Matte
- Reality or Illusion: Did Vermeer’s Interiors ever Exist?
- Color
- Composition
- Mimesi & Illusionism
- Perspective
- Camera Obscura Vision
- Light & Modeling
- Studio
- Four Essential Motifs in Vermeer’s Oeuvre
- Drapery
- Painting Flesh
- Canvas
- Grounding
- “Inventing,” or Underdrawing
- “Dead-Coloring,” or Underpainting
- “Working-up,” or Finishing
- Glazing
- Mediums, Binders & Varnishes
- Paint Application & Consistency
- Pigments, Paints & Palettes
- Brushes & Brushwork
Glue size was often used as a binder to hold the pigment grains firmly in place. It was necessary to apply several coats of azurite to produce a solid blue (fig. 1), but the result was quite beautiful. The actual thickness of the crust of blue added to the richness of the effect, and each tiny grain of the powdered crystalline mineral sparkled like a minute sapphire—especially before it was varnished. Due to the coarseness of azurite it was difficult to use in detail.
Azurite in Vermeer's Painting
In the The Officer and Laughing Girl, azurite is found under a layer of natural ultramarine mixed with lead-tin yellow and traces of lead white in the area corresponding to the shadowed area of the green tablecloth. Azurite was also detected in some of the light gray areas of A Maid Asleep. A
In the The Little Street, the sky was underpainted with lead white, over which the chimneys on the V-shaped roof line were painted. Azurite was used in the underpainting of the three upper windows, including sills and surrounds, of the right house, followed by a creamy yellow layer. The sequence of paint layers is reversed in the ground-floor windows of this house. The foliage was painted with an azurite and lead-tin yellow mixture, three different shades of an ultramarine and lead white mixture, and pure ultramarine.Arthur K. Wheelock Jr. and Ben Broos, Johannes Vermeer (London and New Haven: Yale University Press, 1995), 102.
Azurite is also found mixed with lead-tin yellow in the green window shutters of the Little Street (fig. 3).
"In a few instances, smalt and azurite layers in Vermeer's paintings have been shown to have a protein binding medium, for which there are several recipes in the treatises, among the suggestions made to prevent blue pigments becoming altered by the yellowing of the oil film. Part of the problem was that the better the quality of blues such as ultramarine, azurite, and smalt, the larger their particle size, which caused them to sink in the oil, producing a greenish effect."Nicola Costaras, "A Study of the Materials and Techniques of Johannes Vermeer,"in Vermeer Studies eds., Vermeer Studies (Studies in the History of Art Series) (Washington, DC: National Gallery Washington, 1998), 157.
Vermeer seems to have used azurite in light grays and mixtures of green where the brilliance of ultramarine would not have been appreciable. Like other painters of the time, Vermeer may have used azurite as a base color on which the far more costly natural ultramarine was paintedr over, for economical reasons.
- BOON, J. and OBERTHALER, E., "Mechanical Weakness and Chemical Reactivity Observed in the Paint Structure and Surface of 'The Art of Painting'" in Vermeer: Die Malkunst - Spurensicherung an einem Meisterwerk, exh. cat., Kunsthistorisches Museum, Vienna 2010, 235–53 and 328–35.
- CARYLE, Leslie A. "Beyond a Collection of Data: What We Can Learn from Documentary Sources on Artists' Materials and Techniques." In Historical Painting Techniques, Materials, and Studio Practice: Preprints of a Symposium, edited by Arie Wallert, Erma Hermens, and Marja Peek, 1-5. University of Leiden, the Netherlands, 26-29 June 1995.
- COSTARAS, Nicola. "A Study of the Materials and Techniques of Johannes Vermeer." In Vermeer Studies, edited by Ivan Gaskell and Michiel Jonker, Studies in the History of Art 55, Center for Advanced Study in the Visual Arts, Symposium Papers XXXIII. Washington: National Gallery of Art & New Haven: Yale University Press, 1998, 145–167.
- DELANEY, John K., Kathryn A. Dooley, Annelies van Loon, and Abbie Vandivere. “Mapping the Pigment Distribution of Vermeer’s Girl with a Pearl Earring.” Heritage Science 8, no. 4 (January 7, 2020). Accessed May 2, 2022.
- EASTAUGH, Nicholas, Valentine Walsh, Tracey Chaplin and Ruth Siddall. The Pigment Compendium 2017. Rev. ed. (e-version). London: The Pigmentum Project, 2016.
- FINK, Daniel A. "Vermeer's Use of the Camera Obscura: A Comparative Study." The Art Bulletin 53 (1971).
- GIEBE, Marlies. “Johannes Vermeers ‘Kupplerin’: Restaurierung Und Maltechnische Befunde.” In Uta Neidhardt and Marlies Giebe, eds., Johannes Vermeer: Bei der Kupplerin, 39–64. Exh. cat. Dresden: Michel Sandstein in association with Gemäldegalerie Alte Meister, Staatliche Kunstsammlungen, 2004.
- GIFFORD, E. Melanie, Anikó Bezur, Andrea Guidi di Bagno, and Lisha Deming Glinsman. “The Making of a Luxury Image: Van Aelst’s Painting Materials and Artistic Techniques.” In Tanya Paul, James Clifton, Arthur K. Wheelock Jr., and Julie Hochstrasser, Elegance and Refinement: The Still-Life Paintings of Willem van Aelst, 80–84. Exh. cat. New York: Skira Rizzoli, 2012.
- GIFFORD, M. "Painting Light: Recent Observations on Vermeer's Technique." In Vermeer Studies, edited by Ivan Gaskell and Michiel Jonker. Washington, D.C.: National Gallery of Art & New Haven and London: Yale University Press, 1998, 185–199.
- GIFFORD, E. Melanie, and Lisha Deming Glinsman. “Collective Style and Personal Manner: Materials and Techniques of High-Life 'Genre Painting'.” In Waiboer, Wheelock, and Ducos, Vermeer and the Masters of Genre Painting, 65–84, 270–74.
- GIFFORD, E. Melanie, Dina Anchin, Alexandra Libby, Marjorie E. Wieseman, Kathryn A. Dooley, Lisha Deming Glinsman, John K. Delaney. "First Steps in Vermeer’s Creative Process: New Findings from the National Gallery of Art," Journal of Historians of Netherlandish Art 14, no. 2 (Summer 2022).
- GIFFORD, E. Melanie. “Fine Painting and Eloquent Imprecision: Gabriel Metsu’s Painting Technique.” In Adriaan E. Waiboe, Gabriel Metsu, 154–79. New Haven: Yale University Press in association with the National Gallery of Art, 2010.
- GIFFORD, E. Melanie. “Lievens’ Technique: ‘Wonders in Smeared Paint, Varnishes and Oils.’” In Jan Lievens: A Dutch Master Rediscovered, edited by Arthur K. Wheelock Jr., 41–53. Exh. cat. New Haven: Yale University Press in association with the National Gallery of Art, 2008.
- GIFFORD, E. Melanie. “Material as Metaphor: Non-Conscious Thinking in Seventeenth Century Painting Practice.” In Studying Old Master Paintings: Technology and Practice, edited by Marika Spring, 165–72. London: Archetype in association with The National Gallery, 2011.
- GIFFORD, E. Melanie. “Painting Light: Recent Observations on Vermeer’s Technique.” In Vermeer Studies, edited by Gaskell and Jonker, 185–99.
- GROEN, Karin M., Inez D. van der Werf, Klaas Jan van den Berg, and Jaap J. Boon. "Scientific Examination of Vermeer's 'Girl with a Pearl Earring'." In Vermeer Studies, edited by Ivan Gaskell and Michiel Jonker. Washington, D.C.: National Gallery of Art & New Haven and London: Yale University Press, 1998, 169–183.
- HOMMES, M.H. van Eikema. "Verdigris Glazes in Historical Oil Paintings: Instructions and Techniques." In Discoloration in Renaissance and Baroque Oil Paintings. Instructions for Painters, Theoretical Concepts, and Scientific Data. Dissertation, 2002.
- HOWARD, Helen, David Peggie and Rachel Billinge. "Vermeer and Technique." National Gallery website. https://www.nationalgallery.org.uk/research/about-research/the-meaning-of-making/vermeer-and-technique
- JANSON, Jonathan. Looking Over Vermeer's Shoulder: Seventeenth-Century Painting Techniques and Studio Practices with Particular Focus on the Work of Johannes Vermeer, second edition. USA, 2020.
- KÜHN, Herman. "A Study of the Pigments and the Grounds used by Jan Vermeer." Reports and Studies in the History of Art. Washington: National Gallery of Art, 1968.
- LAURENZE-LANDSBERG, Claudia. “Neutron-Autoradiography of Two Paintings by Jan Vermeer in the Gemäldegalerie Berlin.” In Wolfgang Lefèvre, ed., Inside the Camera Obscura: Optics and Art under the Spell of the Projected Image, 213–25. Berlin: Max-Planck Institute for the History of Science, 2007.
- LEVY-HALM, Koos. “Where Did Vermeer Buy His Painting Materials? Theory and Practice.” In Gaskell and Jonker, Vermeer Studies, 137–43.
- LIBBY, Alexandra, E. Melanie Gifford, Dina Anchin, Marjorie E. Wieseman, Kathryn A. Dooley, Lisha Deming Glinsman, John K. Delaney. "Experimentation and Innovation in Vermeer’s Girl with the Red Hat: New Findings from the National Gallery of Art," Journal of Historians of Netherlandish Art 14, no. 2 (Summer 2022).
- LIEDTKE, Walter A., Richard C. Johnson, and Don H. Johnson. “Canvas Matches in Vermeer: A Case Study in the Computer Analysis of Fabric Supports.” Metropolitan Museum Journal 47 (2012): 101–8.
- LOON, Annelies van, Abbie Vandivere, John K. Delaney, Kathryn A. Dooley, Steven De Meyer, Frederik Vanmeert, Victor Gonzalez, Koen Janssens, Emilien Leonhardt, Ralph Haswell, Suzan de Groot, Paolo D’Imporzano and Gareth R. Davies. “Beauty is Skin Deep: The Skin Tones of Vermeer’s Girl with a Pearl Earring.” Heritage Science 7, no. 102 (December 11, 2019). Accessed May 2, 2022.
- LOON, Annelies van, Alessa A. Gambardella, Victor Gonzalez, Marine Cotte, Wout De Nolf, Katrien Keune, Emilien Leonhardt, Suzan de Groot, Art Ness Proaño Gaibor, and Abbie Vandivere. “Out of the Blue: Vermeer’s Use of Ultramarine in Girl with a Pearl Earring.” Heritage Science 8, no. 25 (February 28, 2020). Accessed May 2, 2022.
- MAHON, Dorothy, Silvia A. Centeno, Margaret Iacono, Federico Carό, Heike Stege and Andrea Obermeier. “Johannes Vermeer’s Mistress and Maid: New Discoveries Cast Light on Changes to the Composition and the Discoloration of Some Paint Passages.” Heritage Science 8, no. 30 (March 27, 2020). Accessed May 2, 2022.
- NEIDHART, Uta, and Marlies GIEBE, with essays by Albert Blankert, Chrisitne Klose, Johann Koller, Annalise Mayer-Meintsschel et al. Johannes Vermeer 'Bei der Kupplerin,' exh. cat. Dresden, 2004.
- PEETERS, Natasja. “The Painter’s Apprentice in Fifteenth and Sixteenth Century Antwerp: An Analysis of the Archival Sources.” Mélanges de l’École française de Rome: Italie et Méditerranée modernes et contemporaines, nos. 131–2 (2019), 221–27, https://doi.org/10.4000/mefrim.6461.
- POTTASCH, Carol. “Underdrawings in the Paintings of Frans van Mieris.” In Quentin Buvelot, Frans van Mieris 1635–1681, 62–68. Exh. cat. Zwolle: Waanders 2005.
- OBERTHALER, E., J. Boon, S. Stanek, and M. Griesser. "'The Art of Painting' by Johannes Vermeer. History of Treatments and Observations on the Present Condition." In Vermeer, Die Malkunst: Spurensicherung an einem Meisterwerk, exh. cat. Vienna: Kunsthistorisches Museum, 2010, 215–234 and 322–327. See especially illustrations 49 and 50.
- SHELDON, L., and N. Costaras. "Johannes Vermeer's 'Young Woman Seated at a Virginal'." The Burlington Magazine 148 (February 2006): 89–97.
- SIVEL, Valerie, Joris Dik, Paul Alkemade, Libby Sheldon, and Henny Zandbergen. “The Cloak of Young Woman Seated at a Virginal: Vermeer, or a Later Hand?” ArtMatters: Netherlands Technical Studies in Art 4 (2007): 90–96.
- SLUIJTER, Eric Jan. “Emulative Imitation among High-Life Genre Painters.” In Waiboer, Wheelock, and Ducos, Vermeer and the Masters of Genre Painting, 36–49.
- STEADMAN, Phillip. Vermeer's Camera: Uncovering the Truth behind the Masterpieces. Oxford: Oxford University Press, 2001.
- STOLS-WITLOX, Maartje. A Perfect Ground: Preparatory Layers for Oil Paintings, 1550–1900. London: Archetype Publications, 2017..
- VANDIVERE, Abbie, Annelies van Loon, Kathryn A. Dooley, Ralph Haswell, Robert G. Erdmann, Emilien Leonhardt, and John K. DELANEY. “Revealing the Painterly Technique beneath the Surface of Vermeer’s Girl with a Pearl Earring Using Macro- and Microscale Imaging.” Heritage Science 7, no. 64 (September 2, 2019). Accessed May 2, 2022.
- VANDIVERE, Abbie, Annelies van Loon, Tom Callewaert, Ralph Haswell, Art Ness Proaño Gaibor, Henk van Keulen, Emilien Leonhardt, and Joris Dik. “Fading into the Background: The Dark Space surrounding Vermeer’s Girl with a Pearl Earring.” Heritage Science 7, no. 69 (September 16, 2019). Accessed May 2, 2022.
- VANDIVERE, Abbie, ed., “The Girl in the Spotlight: A Technical Re-Examination of Vermeer’s Girl with a Pearl Earring.” Special Collection, Heritage Science 7–8 (2019–20). Accessed May 2, 2022.
- VANDIVERE, Abbie, Jørgen Wadum, and Emiliene Leonhardt. “The Girl in the Spotlight: Vermeer at Work, His Materials and Techniques in Girl with a Pearl Earring.” Heritage Science 8, no. 20 (March 2, 2020). Accessed May 2, 2022.
- VANDIVERE, Abbie. “The Technical (Re-)Examination of Vermeer’s Girl with a Pearl Earring.” Heritage Science 8, no. 26 (March 11, 2020). Accessed May 2, 2022.
- VERSLYPE, Ige. “The Restoration of ‘Woman in Blue Reading a Letter’ by Johannes Vermeer.” The Rijksmuseum Bulletin 60, no. 1 (2012): 2–19.
- WALD, Robert. “The Art of Painting: Observations on Approach and Technique.” In Sabine Haag, Elke Oberthaler, and Sabine Pénot, Vermeer, Die Malkunst: Spurensicherung an einem Meisterwerk, 312–27. Exh. cat. St. Pölten: Residenz in association with Kunsthistorisches Museum, Vienna, 2010.
- WALLERT, Arie. “The Materials and Methods of Michiel Sweerts’s Paintings.” In Jansen and Sutton, Michiel Sweerts, 37–47.
- WADUM, Jørgen, René Hoppenbrouwers, and Luuk Struick van der Loeff. Vermeer Illuminated: Conservation, Restoration and Research: A Report on the Restoration of the View of Delft and the Girl with a Pearl Earring by Johannes Vermeer. Wormer: V+K in association with the Royal Cabinet of Paintings Mauritshuis, The Hague, 1994.
- WADUM, Jørgen. "Contours of Vermeer." In Vermeer Studies. New Haven and London, 1998, 201–223.
- WHEELOCK, Arthur K., Jr. Vermeer and the Art of Painting. New Haven: Yale University Press, 1995.
- WIESEMAN, Marjorie E. “Acquisition or Inheritance? Material Goods in Paintings by Vermeer and His Contemporaries.” In Waiboer, Wheelock, and Ducos, Vermeer and the Masters of Genre Painting, 50–63.
- WIESEMAN, Marjorie E., Alexandra Libby, E. Melanie Gifford, Dina Anchin. "Vermeer’s Studio and the Girl with a Flute: New Findings from the National Gallery of Art," Journal of Historians of Netherlandish Art 14, no. 2 (Summer 2022).
